Root Grapple – Light Duty

New 60″ Light-Duty Root Grapple attachment for skid steer / track loaders and compact tractors. Constructed from 3/8″ thick Grade 50 steel throughout, this root grapple features two(2) independent dual grapple assemblies powered by two(2) American made 3,000 psi cylinders. The main frame consists of two(2) 3″ square and one(1) 3″ round pieces of tubed steel supported by seven(7) 3/8″ thick steel tines spaced every 9-10 inches. The optimal tine spacing allows dirt, debris, smaller rocks, and other unwanted loose material to fall through and remain on the job site. Hoses and 1/2″ flat-faced couplers included. The universal quick attach plate fits most makes and models of skid steer loaders and compact tractors. This grapple is ideal for picking up and moving: rocks, logs, brush, scrap, debris or any other odd shaped or hard to move material. Weight is 430 lbs. Available in 60″, 66″ & 72″ sizes.


Compare & Save.
  Made in the USA!



Root Grapple – Light Duty

New 60″ Light-Duty Root Grapple attachment for skid steer / track loaders and compact tractors. Constructed from 3/8″ thick Grade 50 steel throughout, this root grapple features two(2) independent dual grapple assemblies powered by two(2) American made 3,000 psi cylinders. The main frame consists of two(2) 3″ square and one(1) 3″ round pieces of tubed steel supported by seven(7) 3/8″ thick steel tines spaced every 9-10 inches. The optimal tine spacing allows dirt, debris, smaller rocks, and other unwanted loose material to fall through and remain on the job site. Hoses and 1/2″ flat-faced couplers included. The universal quick attach plate fits most makes and models of skid steer loaders and compact tractors. This grapple is ideal for picking up and moving: rocks, logs, brush, scrap, debris or any other odd shaped or hard to move material. Weight is 430 lbs. Available in 60″, 66″ & 72″ sizes.


Compare & Save.
  Made in the USA!



Description

Features

  • Constructed in the U.S.A. with 3/8″ thick American made steel
  • Dual grapples operate independently for uneven loads
  • Seven(7) – 3/8″ thick tines spaced every 9-10 inches
  • Universal quick-attach mount fits most machines
  • Two(2) – 8″ stroke American made cylinders
  • Gusseted grapple tines for added support
  • Recommended for machines under 40 HP
  • Hoses and flat-faced couplers
  • Greaseable pivot points
  • 32″ grapple opening
  • 430 lbs

P/N: Loflin Fabrication 0010301060 , 0010301066 , 0010301072

P/N: Blue Diamond 106055 , 106060

Additional information

Sizes

60", 66", 72"

Fits the Following

Universal Quick Attach – Fits Most Makes & Models

Specifications

WidthOverall DepthInside DepthWeight (LBS)Number of TinesTine ThicknessTine SpacingGrapple OpeningGrapple Thickness
60"31"26"43073/8"9"-10"32"3/8"
66"31"26"46083/8"9"-10"32"3/8"
